1

1633

Motor Chain Guard Bracket - 70" Reverse Only

2

1633-2

Motor Chain Guard Bracket (Used with Platform Type Base)

3

1370-1

Hex. Nut

1/4 - 20

4

1726

Motor Chain Guard - 70" and 75" Inner

1747

Motor Chain Guard

5

1699

Motor Chain Guard Spacer

1700

Motor.Chain Guard Spacer

6

1749

Cap Screw

1/4 - 20 x 1-112

1748

Cap Screw

1/4 - 20 x 2

7

787

Spring

5/8 x 7/8 (60#)

8

923

Washer

11/32 x 3/4 x 1/16

9

744

Hex. Nut

5/16 - 24

10

727-1

Bolt

5/16 - 18 x 2-1/2 Hex. Head

11

1861-1

Hex. Nut

5/16 - 18 Lock Nut

12

1605

Speed Control Bell Crank - Handle Bar

13

1614

Speed Control Rod to Bell Crank

Speed Control Rod to Bell Crank for 25" and 70" Mowers

14

1613-1

Speed Control Rod 30" Long for 7.5 H.P. Motor

15

1607

Speed Control Rod Adjusting Collar

16

1350-2

Set Screw

1/4 - 28 x 1/4 Cup Point

17

1046

1" Conduit Lock Nut (Exhaust Pipe Lock)

18

1499

1" Street Elbow 45o

19

1624

Speed Control Rod to Governor - 7.5 H.P. Motor

20

1606

Speed Control Bell Crank - Governor

21

1888

Shoulder Bushing for Bell Crank (B & S #23849) Item 2 Only

22

1498

Nelson Type Muffler

23

2029

Motor Sprocket 20T. 7.5 H.P. Motor #60 Chain

3/4 - 1/2 x 15/32 - 1" Bore

2029-1

Motor Sprocket 20T. 7.5 H.P. Motor #50 Chain

5/8 - 3/8 x .400 - 1" Bore

2030

Motor Sprocket 17T. #60 Chain

3/4 - 1/2 x 15/32 - 1" Bore

24

761

Set Screw

5/16 - 24 x 7/16 Cup Point 40 P. 30" Long

25

2132

Motor Chain (Item 2 Only)

2247-1

Motor Chain (Item lOx Only)

2247-2

Motor Chain used with 1236-21 and 2030 Sprocket

2248-1

Motor Chain used with 1236-1 and 2029 Sprockets

1262

Motor Chain used with 1236-21 and 1507 Sprocket

26

761

Set Screw

5/16 - 24 x 7/16 Cup Point

27

1772

Motor Sprocket Key - 5, 7.5 and 10 H.P. Motors

1/4 - 1/4 x 3/4

1771

Motor Sprocket Key - 3.5 H.P. Motor .... .......................

3/16 - 3/16 x 13/16

28

1507

Motor Sprocket 20T. Offset - 7.5 H.P. Motor

3/4 P. 1" Bore #60 Chain

1507-1 @

Motor Sprocket 20T. Offset

5/8 x 3/8 x .400 1" Bore #50 Chain

1507-2

Motor Sprocket 17T. Offset

5/8 x 3/8 x .400 1" Bore #50 Chain

1854

Motor Sprocket 17T. Offset - 7.5 H.P. Motor

3/4 x 1/2 x 15/32 1" Bore #60 Chain

29

708

Cap Screw

3/8 - 24 x 1 Hex. Head

724

Hex. Nut

3/8 - 24

30

707

Cap Screw

3/8 - 24 x 3/4 Hex. Head
